ART HeadAmp6Pro Headphone Amplifier

ART HeadAmp6Pro 6-channel Headphone Amplifier Overview ART Pro Audio’s HeadAmp6PRO is a 6-channel stereo headphone amplifier intended for installation applications. The amp has front and rear output jacks with 1/4″ TRS connectors for versatile connection. Input is via XLR and 1/4″ TRS connectors, with matching Thru jacks for connecting numerous amplifiers. A front-panel 1/4″ jack enables simple patch overriding of the rear inputs. The amplifier also has a 6-channel Aux input section, which may be utilized to give the often requested “more me” option on a headphone mix. Each output channel has distinct bass and treble controls, as well as a dual-function balancing control that allows you to pan between the left and right sides of the main signal or change the mix between the main and Aux inputs for that channel. Front-panel Each channel’s mono select buttons enable you to choose between four alternative operating modes: Stereo, Mono Left, Mono Right, and Mono Both, providing a variety of monitoring possibilities. An 8-segment LED level meter gives visual feedback on signal levels on all channels including the main signal bus. ART HeadAmp6Pro 6-headphone Monitoring System Specifications: Professional rack-mounted 6-channel stereo headphone amplifier. Stereo XLR and 1/4″ TRS inputs. Thru jacks to connect extra amplifiers. Auxiliary input portion Front and rear panels. 1/4″ primary outputs may be utilized concurrently. Front-panel 1/4″ auxiliary input for rapid input override. Individual tone, mix, and balance settings for each channel. Choose from four operating modes: Stereo, Mono Left, Mono Right, and Mono Both. LED eight-segment level meter
